Product Overview

This cordless hog ring plier is designed for versatile fastening applications using both 15 GA. and 16 GA. C rings. It supports two hog ring specifications with crown sizes of 23.87 mm and 23.47 mm, wire sizes of 1.8 mm and 1.6 mm, and a closure range of 4.8–8.7 mm. The tool forms C rings with the points facing outward and is suitable for a wide range of applications, including pocket spring mattress assembly, automotive seat assembly, upholstery, bag and mesh bag closure, fencing, greenhouses, and cages.

Available in versions compatible with DeWalt, Makita, Milwaukee, or Bosch battery platforms, the tool provides cordless operation without the limitations of air hoses or compressors. Its compact body and lightweight 1.85 kg design offer greater mobility and easier handling in workshops, production areas, and on-site applications. The 48 mm working length provides extended reach for fastening in deeper and less accessible areas, making it well suited for applications that require improved access while maintaining good maneuverability.

The well-balanced design provides improved control, leverage, and handling during repetitive fastening work, helping reduce operator fatigue. With dual hog ring compatibility, multiple battery-platform support, and a portable cordless design, this tool provides a practical and flexible fastening solution for a variety of industrial and assembly applications.

Comparison Chart for Similar Products

FAQ

1. What’s the difference between C, D, and Omega type hog ring pliers?

Hog ring pliers are classified based on the shape of the rings they work with. C-type pliers are the most commonly used, suitable for general fastening tasks such as fencing, automotive seats, and bag closures. D-type pliers are designed for D-shaped rings, often used in specific mechanical or agricultural applications. M (Omega) type pliers are made for fastening with Omega-shaped rings, which offer wider coverage and are ideal for tasks like assembling cages or securing mesh in larger surface areas. Choosing the right type depends on the ring shape required for your application.

【Extending reading: Mastering Hog Ring Pliers: 9 Reasons You Need This Essential Tool】

2. How do battery and pneumatic C ring pliers compare?

Battery C ring pliers offer greater mobility because they do not require an air hose and compressor, making them convenient for on-site work or areas where compressed air is not available.

Pneumatic C ring pliers are generally better suited for continuous, high-volume production because they can operate for long periods without battery charging. The best choice depends on whether portability or continuous production efficiency is the priority.
【Extending reading: Pneumatic vs. Electric Nailer: How to Choose the Best Option for Your Workflow】

3. What is the difference between “outward-forming” and “inward-forming”?

Outward-forming and inward-forming refer to the direction of the C-ring points after the ring is closed. With outward-forming, the sharp points remain on the outer side of the formed ring, while inward-forming directs the points toward the inside of the ring.

Both forming styles can be used for applications such as mattress assembly, automotive seating, upholstery, fencing, wire mesh, and cages. The preferred style depends on the application, material, and required finished shape. Inward-forming can help reduce exposed sharp points on the outer surface, while outward-forming is a conventional forming style commonly used in many fastening applications.
